Composite wallboard is a new generation of high-performance building internal partition. It replaces the traditional brick and tile. It has the advantages of environmental protection, energy conservation, no pollution, fire prevention and thermal insulation, sound insulation and earthquake resistance. What are the specifications of composite wallboard and how to install it? If you are interested, let's get to know it with the European School Xiaobian.

复合墙板是新一代高性能建筑内隔板，它代替了传统的砖瓦，具有环保节能无污染，防火保温，隔音抗震等优点。那么复合墙板规格多少以及如何安装呢？>复合墙板规格多少

Composite wallboard is a new generation of high-performance building internal partition. It replaces the traditional brick and tile. It has the advantages of environmental protection, energy conservation, no pollution, fire prevention and thermal insulation, sound insulation and earthquake resistance. What are the specifications of composite wall panels and how to install them? > What is the specification of composite wallboard

复合墙板规格有很多，不同种类的复合墙板其规格也各不相同。

There are many specifications of composite wallboards, and the specifications of different types of composite wallboards are also different.

彩钢复合墙板厚度有50mm、75mm、100mm等，其芯层有岩棉、泡沫两类。岩棉一般使用密度有80公斤/立方米、100公斤/立方米、120公斤/立方米、140公斤/立方米、160公斤/立方米、180公斤/立方米；泡沫一般使用密度有6公斤/立方米、8公斤/立方米、10公斤/立方米等。上下彩钢防腐层保持期为10-15年，彩色镀铝锌防腐层保持为30-45年，彩钢板厚度为0.17-0.6mm之间。

The thickness of color steel composite wallboard is 50mm, 75mm, 100mm and so on. The core layer has two types: rock wool and foam. The general use density of rock wool is 80kg / m3, 100kg / m3, 120kg / m3, 140kg / m3, 160kg / m3 and 180kg / m3; The general density of foam is 6 kg / cubic meter, 8 kg / cubic meter, 10 kg / cubic meter and so on. The retention period of upper and lower color steel anticorrosive coatings is 10-15 years, the retention period of color aluminum zinc anticorrosive coatings is 30-45 years, and the thickness of color steel plates is between 0.17-0.6mm.

铝塑复合墙板的厚度，常见是3-10mm，标准长度是2440mm，非标准可以加长到6000mm多，当然也可以短于1000mm，标准宽度一般均是1220mm，也有1000mm，宽可以做到2000mm。

The thickness of aluminum-plastic composite wallboard is usually 3-10mm, the standard length is 2440mm, non-standard can be extended to more than 6000mm, of course, it can also be shorter than 1000mm, the standard width is generally 1220mm, there are also 1000mm, and the maximum width can be 2000mm.

聚氨酯复合墙板容重范围为40-60kg/m3,长度范围是0.5-4m，宽度范围为0.5-1.2m，厚度范围为20-200mm，切割精度高，厚度误差是0.5mm左右。

The unit weight range of polyurethane composite wallboard is 40-60kg / m3, the length range is 0.5-4m, the width range is 0.5-1.2m, the thickness range is 20-200mm, the cutting accuracy is high, and the thickness error is about 0.5mm.

复合墙板怎么安装呢？

How to install the composite wallboard?

1、首先是要看好设计图纸，根据放样的设计图纸来进一步的确定木榫的尺寸以及规格，然后在根据设计图纸来确定墙面弹线、复合墙板加工地。

1. First of all, we should pay attention to the design drawings, further determine the size and specification of the wooden tenon according to the setting out design drawings, and then determine the wall snapping line and the processing place of the composite wallboard according to the design drawings.

2、钻孔固定需要使用的是60*M8的膨胀螺丝来做一个稳固，在使用十二毫米的钻头来进行打孔，孔的深度大概在四十五毫米之间。

2. The 60 * M8 expansion screw shall be used for drilling fixation to make a firm. A 12mm drill bit shall be used for drilling, and the depth of the hole is about 45mm.

3、将60*M8的膨胀螺丝放到孔里，如果施工的现场已经进行到了预埋阶段的话，需要对复合墙板隔断轴线的位置放好定位线，然后固定好地面装饰表面水平和轴线基准点。

3. Put the 60 * M8 expansion screw into the hole. If the construction site has reached the embedding stage, it is necessary to set the positioning line at the position of the partition axis of the composite wallboard, and then fix the ground decoration surface level and axis reference point.

4、同时还需要对轻质隔墙板每个跨度之间尺寸的复核，经过仔细确认好之后在根据设计图纸立柱水平间距在对预埋件进行防锈处理的分布，符合要求之后在使用膨胀螺丝来稳固。

4. At the same time, it is also necessary to recheck the size between each span of the light partition board. After careful confirmation, the expansion screw shall be used to stabilize the embedded parts after the distribution of anti rust treatment according to the horizontal spacing of columns in the design drawing meets the requirements.
